Standard:
|
TCP/IP
|
Supported resolutions:
|
8 @ 3840 x 2160 px, 8 @ 1920 x 1080 px, 8 @ 1280 x 720 px, 8 @ 704 x 576 px
|
Video outputs:
|
1 pcs HDMI 1 pcs VGA
|
Audio support:
|
8 Channels - Audio from cameras
|
Audio inputs:
|
1 pcs CINCH - External microphone input
|
Audio outputs:
|
1 pcs CINCH
|
Image compression method:
|
H.265 / H.264 / MJPEG
|
Maximal total frame rate:
|
200 fps @ 3840 x 2160 px, 200 fps @ 1920 x 1080 px, 200 fps @ 1280 x 720 px, 200 fps @ 704 x 576 px
|
Supported hard drives:
|
1 x 6 TB SATA
|
Recording modes:
|
Manual, Motion Detection, Schedule
|
Network protocols:
|
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, IP Filter, PPPoE, FTP, IP Search, ONVIF 2.4
|
External storage devices backup:
|
Backup to USB drive (pendrive)
|
Searching and playback the records:
|
Records searching: by time and events type. Records playback: forward, backward, fast, slow Advanced searching (to the one second accuracy) All channels synchronous playback, Smart Search function
|
Bitrate:
|
max. 80 Mb/s
|
Network functions:
|
Full support via network, Remote records copying, Web Server built-in max. 128 on-line users
|
ONVIF:
|
2.4
|
Mobile phones support:
|
Port no.: 37777 or access by a cloud
· Android: Free application gDMSS Lite, Android: Free application Easy4ip
· iOS (iPhone): Free application iDMSS Lite, iOS (iPhone): Free application Easy4ip There are also paid versions of mobile applications: gDMSS Plus, iDMSS Plus
|
Default admin user / password:
|
admin / admin
|
Default IP address:
|
192.168.1.108
|
Web browser access ports:
|
80, 37777
|
PC client access ports:
|
37777
|
Mobile client access ports:
|
37777
|
Port ONVIF:
|
80
|
Multi-operation:
|
Pentaplex
|
Alarm inputs / outputs:
|
No
|
PTZ control:
|
IP Speed Dome Cameras
|
Motion Detection:
|
22 x 18 motion zones - after motion detection records detected channels only
|
Mouse support:
|
Yes
|
IR remote controller in the set:
|
No
|
Power supply:
|
12 V DC / 2 A (power adapter included)
|
Weight:
|
0.45 kg
|
Dimensions:
|
Smart 1U, 205 x 205 x 46 mm
|
Supported languages:
|
English
|
Country of origin:
|
China
|
Manufacturer / Brand:
|
DAHUA
|
