Camera Module
|
|
Image Sensor
|
1/2.8" progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON)
|
|
White Balance
|
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
|
|
AGC
|
Auto/Manual
|
|
Day & Night
|
IR Cut Filter
|
|
Shutter Time
|
1/1 s to 1/30,000 s
|
|
Digital Zoom
|
16X
|
|
Privacy Mask
|
24 programmable privacy masks
|
|
Focus Mode
|
Auto/Semi-automatic/Manual
|
|
WDR
|
120 dB
|
|
Lens
|
|
Focal Length
|
4.8 mm to 120 mm, 25× optical
|
|
Zoom Speed
|
Approx. 3.2 s (optical lens, wide-tele)
|
|
Field of View
|
Horizontal field of view: 57.6° to 2.5° (wide-tele) Vertical field of view: 34.4° to 1.4° (wide-tele) Diagonal field of view: 64.5° to 2.9° (wide-tele)
|
|
Working Distance
|
10 mm to 1500 mm (wide-tele)
|
|
Aperture Range
|
F1.6 to F3.5
|
|
IR
|
|
IR Distance
|
Up to 100m
|
|
Smart IR
|
Support
|
|
PTZ
|
|
Pan and Tilt Range
|
Pan:360° endless; Tilt: -15°~90°(Auto Flip)
|
|
Pan and Tilt Speed
|
Configurable, from 0.1°/s to 80°/s Preset Speed: 80°/s Configurable, from 0.1°/s to 80°/s Preset Speed: 80°/s
|
|
Proportional Zoom
|
Support
|
|
Number of Preset
|
300
|
|
Patrol
|
8 patrols, up to 32 presets for each patrol
|
|
Pattern
|
4 pattern scans, record time over 10 minutes for each scan
|
|
Power-off Memory
|
Support
|
|
Park Action
|
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
|
|
PTZ Position Display
|
Support
|
|
Preset Freezing
|
Support
|
|
Scheduled Task
|
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust
|
|
Compression Standard
|
|
Video Compression
|
H.265+/H.265/H.264+/H.264
|
|
H.264 Type
|
Baseline Profile/Main Profile/High Profile
|
|
H.264+
|
Support
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Support
|
|
Video Bitrate
|
32 Kbps to 16384 Kbps
|
|
Audio Compression
|
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM
|
|
Audio Bitrate
|
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2)
|
|
SVC
|
Support
|
|
Smart Feature
|
|
Basic Event Detection
|
Motion Detection, Video Tampering Detection, Exception Detection
|
|
Smart Event Detection
|
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection, Audio Exception Detection
|
|
ROI encoding
|
Main stream, sub-stream and third stream respectively support four fixed areas.
|
|
Smart Record
|
ANR (Automatic Network Replenishment), Dual-VCA
|
|
|
|
Max. Image Resolution
|
1920 x 1080
|
|
Stream
|
Support three Streams
|
|
Main Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Image Enhancement
|
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
|
|
Network
|
|
Network Storage
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
|
API
|
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
|
|
Simultaneous Live View
|
Up to 20 channels
|
|
User/Host
|
Up to 32 users. 3 levels: Administrator, Operator and User
|
|
Security Measures
|
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
|
|
Client
|
iVMS-4200, Hik-Connect
|
|
Web Browser
|
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
|
|
Mini SD Memory Card
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
|
|
Interface
|
|
Audio Input
|
1-ch
|
|
Audio Output
|
1-ch
|
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet Interface; PoE+
|
|
General
|
|
Power
|
12 VDC & PoE+ (802.3at, class4), Max.:18 W (IR Max.6 W)
|
|
Working Temperature
|
-30°C to 65°C (-22°F to 149°F)
|
|
Working Humidity
|
≤ 90%
|
|
Protection Level
|
IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Material
|
ADC 12, PC+10% GF
|
|
Dimensions
|
Φ 165.9 mm × 290 mm (Φ 6.53" × 11.42")
|
|
Weight (approx.)
|
Approx. 2.5 kg (5.51 lb)
|
