Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions. With advanced deep learning algorithm, Dahua WizSense 3 Series network camera supports intelligent functions, such as perimeter protection and smart motion detection. With starlight technology, this series camera provides a better image effect in the condition of low illuminance.
Siren and Light Active Deterrence
Dahua siren and light active deterrence network camera supports the light alarm and voice alarm when perimeter event occurs, to realize the deterrence and effective intervention. The camera is built in multiple voices for selection, and supports customized voice importing.
Smart Dual Illuminators
Dahua Smart Dual Illuminators technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the warm light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the warm light is off and the IR illuminator is on, which reduces light pollution efficiently.
SMD 3.0
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
One-tap Disarming
Dahua One-tap Disarming function, which is convenient and easy for operation, is the switch for event linkage. Customers can close and recover event linkage through mobile App, which meets multi-scenarios needs.
Cyber Security
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.
Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Features
- 1/2.7” progressive scan CMOS 5.0 Megapixel
- Resolution - 5mpx (2592 × 1944); 4mpx (2688 × 1520); 3Mpx (2304×1296); 1080p (1920×1080); 1.3M (1280×960); 720p (1280×720); D1 (704×576/704×480); VGA (640 ×480); CIF (352 × 288/352 × 240).
- Video Frame Rate (3 strams) - Main stream (2592 × 1944@1–20 fps)/2688 × 1520@(1 fps–30 fps) - Sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps) - Third stream (1920 × 1080@1–25/30 fps).
- Support H.265+ / H.265 / H.264 / H.264+ & MJPEG triple-stream encoding.
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
- IVS analysis - crossing the line (tripwire), intrusion - classification of people and vehicles, scene changing, audio detection.
- SMD PLUS 3.0 - searching for an object classified as: human, motor vehicle, non-motor vehicle
- OSD functions: Real WDR 120dB, Day/Night(ICR), ROI, 3D-DNR, AWB, AGC, BLC, HLC, Smart Light, Mirror, Privacy Masking.
- Special functions: Active deterrence with red blue light, siren and alarm out interface.
- Audio: Built-in Mic - Compression: PCM; G.711a; G.711Mu; G.726; G.723.
- Audio Interface I/O: 1/1 audio (RCA) inputs/output;
- Alarme interface I/O: 1/1 alarm inputs/output;
- One press arming/disarming through alarm input.
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
- 2.8mm fixed lens - Built-in warm light and IR LED; the max. IR illumination distance is 30m and warm light distance is 30m (Starlight Full-color).
- Micro SD memory - Micro SD memory cards up to 256GB support (possible local recording)
- Metal structure with IP67 Waterproof protection rating.
Standard:
TCP/IP
Sensor:
1/2.7 " Progressive Scan CMOS
Matrix size:
5 Mpx
Resolution:
2592 x 1944 - 5 Mpx ,
2688 x 1520 - 4 Mpx ,
2560 x 1440 - 3.7 Mpx ,
2304 x 1296 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 960 - 1.3 Mpx ,
1280 x 720 - 720p
Scanning system:
Progressive
Lens:
fixed-focal 2.8 mm - F1.0, M12
View angle:
128° x 97° x 70° (diagonal x horizontal x vertical)
Min. Illuminatio
0.003 lux@F1.0 (Color, 30 IRE) 0.0003 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on)
S/N Ratio
﹥ 56 dB
Illumination Distance
30 m (98.43 ft) (IR) 30 m (98.43 ft) (warm light)
Illuminator Number
1pcs (IR LED) 1pcs (warm light)
S/N ratio:
> 56 dB
RS-485 interface:
No
Memory card slot:
Micro SD memory cards up to 256GB support (possible local recording)
Image compression method:
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Alarm inputs / outputs:
1 / 1
Audio:
External microphone input,
Audio output
Bi-directional audio streaming support
Audio detection
Main stream frame rate:
20 fps @ 5 Mpx
25 fps @ 4 Mpx
Network interface:
10/100 Base-T (RJ-45)
Network protocols:
IPv4/IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
WEB Server:
Built-in
Max. number of on-line users:
20 (Total bandwidth: 72 M)
ONVIF:
20.06
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P)
Android: Free application DMSS
iOS (iPhone): Free application DMSS
Default IP address:
192.168.1.108
Default admin user / password:
admin / - The administrator password should be set at the first start
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
Port ONVIF:
80
Main features:
WDR - 120 dB - Wide Dynamic Range
3D-DNR - Digital Noise Reduction
ROI - improve the quality of selected parts of image
BLC/HLC - Back Light / High Light Compensation
Day/Night mode (color/b&w/auto)
Full Color - colorful night mode
WB - White Balance (ATW/AWB/manual/indoor/outdoor)
AGC - Automatic Gain Control
Motion Detection
Configurable Privacy Zones
Mirror - Mirror image
Light and sound alarm
Active deterrence function
White light (LED) illuminator built-in
SMD PLUS - searching for an object classified as: human, motor vehicle, non-motor vehicle
IVS analysis : crossing the line (tripwire), intrusion - classification of people and vehicles, scene changing, Audio detection
Power supply:
PoE (802.3af),
12 V DC / 610 mA
Power consumption:
max. 8 W @ PoE max. 7.3 W @ 12 V
Housing:
Dome - Metal
Color:
White
"Index of Protection":
IP67
Vandal-proof:
No
Operation temp:
-40 °C ... 60 °C
Weight:
0.745 kg
Dimensions:
110.9 mm × Φ122.0 mm (4.4" × Φ4.8"
Supported languages:
Polish, English, Czech, French, Spanish, Dutch, German, Russian, Portuguese, Romanian, Ukrainian, Hungarian, Italian
Manufacturer / Brand:
DAHUA
