CCTV Tester AHD / HDCVI / HDTVI / PAL 7 "portable CCTV camera power bank camera

NO BRAND

CCTV Tester AHD / HDCVI / HDTVI / PAL 7 "portable CCTV camera power bank camera

Name: CCTV Tester AHD / HDCVI / HDTVI / PAL 7 "portable CCTV camera power bank camera
SKU: 90STX-1
Price: 251.5 EUR
Availability: OutOfStock

(1)

Out of stock

SKU: 90STX-1

Description

Professional Tester AHD, HD-CVI, HD-TVI, PAL for analogue systems up to 1080p , with 7 "LCD display for the installation and adjustment of CCTV cameras.

With this device you can test analog cameras (CMOS - CCD - AHD, HD-CVI, HD-TVI, PAL), allowing you to check the angle of view, focus, brightness and set the various functions of the cameras .

stx1 was designed for the professional installer and can be used in many situations and projects for the setup, calibration, control and testing of any video surveillance system, can check the conditions of the cameras with ease and speed, allowing you to save a lot on the times and costs of installation.

Specifications

Video Input: HDMI-VGA, BNC,
Video Output: BNC, COMPOSITE VIDEO
Control signal generator
Multilingual OSD menu, including Italian language.
Power source DC 12V / 2A - Li-Ion battery 12.6 V

Data sheet

Standard :	AHD - 1080p , HD-CVI - 1080p , HD-TVI - 3 Mpx , PAL , NTSC
Screen format :	7 "
Native resolution :	800 x 480 px
Image adjustment :	Yes
Suspension function :	Yes
OSD screen menu :	Yes
Video Input :	1 unit - AHD / HD-CVI / HD-TVI , BNC socket 1 unit - PAL , BNC socket 1 VGA unit (D-Sub 15-pin) 1 HDMI unit - 1080p
Video Output :	1 composite video unit (Cinch socket) , 1 AHD unit, HD-CVI , HD-TVI - Cinch socket supplied with the USB / 2 x Cinch cable
Audio Input :	No
Audio Output :	No
Operation as a source of energy :	12 V DC / 2 A
Battery powered :	Li-Ion battery
Power supply :	12.6 V Li-Ion Battery, 2600 mAh 12.6 V DC / 1 A (power supply supplied)
Battery life :	max. 17 hours
Selected features :	Access to the OSD menu of HD-TVI cameras via coaxial cable Power source DC 12V / 2A
Operating temperature :	-10 ° C ... 50 ° C
Relative humidity of the admissible environment :	30% ... 90%
Weight :	0.655 kg
Dimensions :	205 x 155 x 40 mm
Supported languages :	English, Traditional Chinese, Simplified Chinese, French, Spanish, Japanese, Korean, German, Russian, Italian
Warranty :	2 years
