75W 24Vdc 3.2A Single Output Switching Power Supply Mean Well LRS-75-24

75W 24Vdc 3.2A Single Output Switching Power Supply Mean Well LRS-75-24

Name: 75W 24Vdc 3.2A Single Output Switching Power Supply Mean Well LRS-75-24
SKU: LRS-75-24
Price: 15.05 EUR
Availability: InStock

In stock

SKU: LRS-75-24

qty: 71

Description

75W 24Vdc 3.2A Single Output Switching Power Supply Mean Well LRS Series Mod. LRS-75-24

LRS-75 series is a 75W singl e-output enclosed type power supply with 30mm of low profile design. Adopting the input of 115VAC or 230VAC(selectable by switch), the entire series provides an output voltage line of 12V, 15V, 24V, 36V and 48V.

In addition to the high efficiency up to 90%, the design of metallic mesh case enhances the heat dissipation of LRS-75 that the whole series operates from -30°C through 70°C under air convection without a fan. Delivering an extremely low no load power consumption (less than 0.5W), it allows the end system to easily meet the worldwide energy requirement. LRS-150 has the complete protection functions and 5G antivibration capability; it is complied with the international safety regulations such as TUV EN60950-1, EN60335-1,EN61558-1/-2-16, UL60950-1 and GB4943. LRS-75 series serves as a high price to performance power supply solution for various industrial applications.

Features

AC input range selectable by switch
Withstand 300VAC surge input for 5 second
No load power consumption <0.5W
Miniature size and 1U low profile
High operating temperature up to 70°C
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1, -2-16 for household appliances
Operating altitude up to 5000 meters
Withstand 5G vibration test
High efficiency, long life and high reliability
LED indicator for power on
100% full load burn-in test

Applications

Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliance

Data sheet

Primary Output Voltage (VDC)	24
Output Current (A)	3.2
Maximum Output Power (W)	75
Family	LRS-75
Input Voltage (VAC)	85 to 264
Input Frequency	47 to 63
Output Connector Type	Screw Terminal Block
Number of Outputs	1
Product Type	AC to DC Power Supply
Efficiency (%)	90
Operating Temperature-Min (Cel)	-30
Operating Temperature-Max (Cel)	70
Dimension	999730mm (LWH)
Agency Approvals	TUV/CB/CE
Color	Silver
Type	Auto Switching
Style	Enclosed
